Holang Modular PSA Nitrogen Generator

NMX

Membrane nitrogen generators utilize membrane separation technology. Clean and dry compressed air enters one or more membrane modules, where gas components with faster permeation rates (such as H2O, H2, Q2, etc.) preferentially permeate through the membrane wall and get enriched on the low-pressure permeate side. Gas components with relatively slower permeation rates (such as N2, etc.) are enriched on the high-pressure retentate side. This process enables the production of nitrogen gas with the desired purity.

FEATURE

High efficiency and energy saving, with prominent cost advantages: Utilizing hollow fiber membrane nitrogen production technology, the purity of nitrogen can reach 99.95%. The core membrane group has a lifespan of 5 to 8 years, during which no adsorbent needs to be replaced. The price of equipment of the same specification is approximately 60 to 70% of that of the PSA system.
Safe and reliable, ready to use immediately: Nitrogen can be produced simply by powering on. Equipped with a multi-stage filtration system to ensure the purity of nitrogen and enhance the stability of the equipment. The product has passed certifications such as CE and ISO, and is widely used in laboratories and industrial fields.
Compact structure and flexible deployment: Unique two-stage shock absorbers and high-efficiency sound-absorbing cotton reduce vibration and noise during operation. Customizable high-traffic model;
Intelligent control and management, convenient operation and maintenance: LCD display, monitoring of instrument operation status, with maintenance reminder function to ensure long-term stable operation. An optional intelligent cloud platform is available for remote control and monitoring via a mobile phone. The automatic drainage function can adjust the drainage time and interval Settings according to the operation time.

Technical principle: Membrane separation
Nitrogen flow rate: 1200m³/h
Nitrogen purity: 95%
Nitrogen outlet pressure: 0.6-0.9MPa
Ambient temperature: 5 to 40℃
Maximum altitude: ≤2000m
Dimensions: 4100*2200*2500mm (LxWxH)
Weight: 3500 kg
Electrical system: 380V/50Hz
Power: 35KW
Specification: ISO9001:2015, CE
Optional: ① Intelligent cloud platform, enabling online control and monitoring via mobile phone. ② Maintenance reminder
